Boom/Stick Option (Hex) 1
| Max Cutting Height | 1574 mm |
| Max Loading Height | 2485 mm |
| Max Reach Along Ground | 3817 mm |
| Max Digging Depth | 2197 mm |
| Boom/Stick Option (Hex) 1 | standard None |
Dimensions
| Width To Outside Of Tracks | 980 mm |
| Length Of Track On Ground | 1114 mm |
| Ground Clearance | 179 mm |
| Tail Swing Radius | 1068 mm |
Undercarriage
| Shoe Size | 230 mm |
Engine
| Engine Make | 2334 None |
| Gross Power | 11.7 kw |
Operational
| Operating Weight | 1580 kg |
| Hydraulic System Relief Valve Pressure | 17200 kPa |
| Hydraulic Pump Flow Capacity | 30 L/min |
